Solar Pond Filter System with Integrated Pump | 1400 LPH
Professional solar-powered filtration system with integrated pump technology, delivering crystal-clear water for ponds up to 2000 litres. Features dual-stage filtration and smart battery backup for reliable 24/7 operation.
Advanced Filtration Technology
Complete dual-stage filtration system for optimal water clarity
Mechanical filtration removes debris up to 7mm
Biological filtration with zeolite/gravel options
Integrated 1400 LPH circulation system
Perfect for ponds up to 2000 litres
Professional Filtration Media
Choice of premium filtration media for optimal water quality
Zeolite option for superior ammonia removal
Sustainable gravel option for bacterial colonization
Double-layer foam filter system
Easy-clean maintenance design
Reliable Solar Power
Sustainable power solution with smart backup
High-efficiency solar panel
Lithium battery backup system
Prolonged consistent operation
Zero running costs
Versatile Operation
Multi-functional system with added features
Optional fountain display
Compatible with water features
Adjustable flow control
Easy installation system
Technical Specifications
Flow Rate
1400 litres per hour
Pond Size Suitability
Up to 2000 litres
Filter Type
Dual-stage (Mechanical & Biological)
Power Source
Solar with Battery Backup
This professional-grade solar pond filter system combines advanced filtration technology with reliable solar power to deliver exceptional water quality. Perfect for small to medium ponds, it offers maintenance-free operation and crystal-clear results. Complete with battery backup and versatile display options, it's the ideal solution for eco-conscious pond owners.
Rate this product
0/5
0 Reviews
Please rate this product, describe its advantages and disadvantages, please share your impression about its use
Complete setup instructions for your solar pond filter system with battery backup
Components Included
Solar Panel & Battery Box
Water Pump / Filter Box / Mesh Medium
Five Meters of Cable between Pump and Battery Box
Ground Stake
Important: Before assembly, wash the zeolite thoroughly with a hose to remove any dust created during transit. This ensures maximum filtration efficiency.
Step 1: Location Planning
Select a location that receives ample sunlight for optimal solar panel efficiency. Ensure the chosen spot allows easy access for maintenance.
Step 2: Solar Panel Mounting
The solar panel features an aluminum frame that's suitable for various mounting options:
Ground Mounting (Included)
Insert the ground stake into the soil at the desired location
Attach the solar panel to the stake using the provided hardware
Tilt the solar panel towards the sun for maximum exposure
DIY Mounting Options
The aluminum frame allows for easy custom mounting solutions
Suitable for bolting to walls or other sturdy surfaces
Ensure secure mounting while maintaining proper panel angle
Step 3: Filter Box and Pump Installation
Place the pump inside the filter box
Feed the pump cable through the filter top hole
Install filter medium (gravel or zeolite) around the pump
Secure upper foam filters and close the filter box
Position filter box in pond with necessary tube extenders
Ensure level and stable placement
Optional: Attach LED lights over extension tubes
Step 4: Battery Box & Panel Connection
Locate the battery box
Connect pump cable to designated battery box port
Secure all connections and manage cables
Connect battery box to solar panel
Step 5: System Activation
Power on using battery box switches
System will automatically use solar power during daylight
Battery backup activates during low-light periods
Step 6: Maintenance Requirements
Regular cleaning of filter box and pump
Monitor battery status during cloudy periods
Seasonal solar panel angle adjustments
Important Safety Tips
If custom-mounted, regularly check mounting security
Maintain clear solar panel exposure
Ensure proper water circulation around filter box
Following these installation instructions will help you achieve efficient and sustainable pond water management with your solar-powered filter system.
A Solar Powered Pond Filter with battery backup harnesses solar energy to power an advanced water filtration system, ensuring your pond stays clean and healthy around the clock.
Pump Performance Metrics
Performance Metric
Flow Rate
Operating Voltage
12.8V
At 0m Height
1400 LPH
At 0.3m Height
1200 LPH
At 0.6m Height
980 LPH
At 0.9m Height
760 LPH
At 1.2m Height
560 LPH
At 1.5m Height
350 LPH
Maximum Height
2.0M
1. Solar Panel Absorption
Advanced photovoltaic cells convert sunlight into DC electricity
Efficient energy conversion for reliable system operation
2. Power Generation and Storage
Direct power utilization for immediate filtration needs
Excess energy stored in rechargeable battery for continuous operation
3. Advanced Filtration System
Integrated water pump and filtration media
Comprehensive debris removal and bacterial growth promotion
4. Mechanical Filtration Process
Efficient circulation through mechanical filters
Captures leaves, twigs, and larger debris
5. Biological Filtration Action
Creates optimal environment for beneficial bacteria
Converts harmful compounds into safer substances
6. Water Circulation System
Enhanced water movement and oxygenation
Prevents stagnation and promotes healthy aquatic environment
7. Battery Backup System
Automatic switching to battery power during low light
Ensures continuous filtration 24/7
8. Automated Operation
Smart sensors for optimal system management
Extended backup capacity for multiple low-light days
9. Smart Charging System
Simultaneous power supply and battery charging
Efficient energy management for reliable operation
This innovative combination of solar power and battery backup delivers an energy-efficient, sustainable solution for maintaining pristine pond water quality, ensuring reliable operation regardless of weather conditions in summer.
